Blackhawk 4G Trucker Edge Compact LITE Antenna 700 to 2200 MHz SMA Male
Blackhawk 4G Trucker Edge Compact LITE Antenna 700 to 2200 MHz SMA Male
Description::
The Blackhawk 4G Trucker Edge Compact LITE Antenna 700 to 2200 MHz SMA Male is designed to meet the demands of both 3G and 4G networks across Australia. With a frequency range of 698 to 2200 MHz this antenna ensures reliable voice and data communication making it ideal for commercial and industrial applications where dependable connectivity is crucial.
Key Features:
- 698-960 MHz and 1710-2170 MHz Frequency Range
- 4 dBi to 5 dBi Gain
- ≤2.0 VSWR
- Vertical polarisation.
- 360° Horizontal Beamwidth
- 48° Vertical Beamwidth
- 50 Ohms Input Impedance
- 50W max. Power Handling
- Copper Reflector
- Fibreglass Radome
- 60cm in height
Optimised Design for Durability
Featuring a sleek 60 cm design the Trucker Edge Compact LITE is lighter than its counterpart weighing only 1.2 kg. Its streamlined barrel design not only reduces weight but also minimises vibrations making it suitable for use on corrugated roads and in harsh environments. This design improvement enhances durability and reduces potential damage during transit.
Advanced Signal Gain
The antenna provides a gain of 4 dBi in the lower frequency range (698-960 MHz) and 5 dBi in the higher range (1710-2200 MHz). This gain enhances signal strength ensuring better coverage and connectivity for your 4G network needs.
Versatile Mounting Options
Equipped with an SMA-Male connector and a 4.5-meter coax cable the Blackhawk Trucker Edge Compact LITE offers flexible installation options. It can be mounted on a car bonnet or bull bar making it adaptable to various vehicle types and ensuring optimal signal reception.
Crafted for Extreme Conditions
Built to withstand extreme conditions this antenna features a rugged construction that is capable of handling temperatures from -40 °C to +65 °C. The durable copper reflector and fibreglass radome ensure the antenna performs reliably in harsh environments.
Comprehensive Coverage
With a vertical beam width of 48° and a horizontal beam width of 360° the Trucker Edge Compact LITE provides broad and even signal coverage. This wide beam width ensures consistent performance regardless of the direction of the signal source.
Enhanced Safety Features
The antenna is designed with built-in lightning protection and operates at a maximum power of 50 watts. This feature ensures that your equipment remains safe from electrical surges and extends the longevity of your antenna in demanding conditions.
Specification:
| Category | Specification | Details |
|---|---|---|
| Model Number | ANT-BH-00030 | Blackhawk 4G Trucker Edge Compact LITE Antenna |
| Frequency Range | 698-960 MHz / 1710-2170 MHz | Supports a wide range of 3G and 4G frequencies |
| Gain | 4 dBi (698-960 MHz) 5 dBi (1710-2170 MHz) | Signal boost depending on frequency range |
| VSWR | ≤2.0 | Voltage Standing Wave Ratio |
| Polarisation | Vertical | Vertical signal polarisation |
| Horizontal Beamwidth | 360° | Omnidirectional coverage |
| Vertical Beamwidth | 48° | Coverage angle in vertical plane |
| Input Impedance | 50 Ohms | Standard impedance for antennas |
| Max Power | 50 W | Maximum power capacity |
| Lightning Protection | DC Ground | Protection against lightning strikes |
| Connector | SMA Male with 4.5 m Coax Cable | Standard RF connector with cable |
| Dimensions | Ø16 x 600 mm | Compact size for mounting |
| Weight | 1.2 kg | Lightweight design |
| Reflector Material | Copper | Material used for reflector |
| Radome Material | Fibreglass | Durable radome material |
| Antenna Colour | Black | Standard Colour Option |
| Operating Temperature | -40 °C to +65 °C | Temperature range |
| Mounting Pole | Ø38-52 mm | Compatible mounting pole diameter |
@14/29
Description::
The Blackhawk 4G Trucker Mini Antenna 698 to 2700 MHz SMA Male is the ultimate solution for mobile applications designed to provide high-performance cellular reception. With a compact 400 mm length it’s ideal for vehicles allowing seamless communication in both rural and urban environments. This antenna completes the Blackhawk Trucker Series combining high gain and wideband coverage across multiple networks in Australia.
Combine with a CEL-FI vehicle booster to never be out of contact when away from home. The antenna has an SMA male connector which will screw directly into your CEL-FI vehicle booster providing full signal inside your car or truck. All Blackhawk Antennas come with a 5-year warranty.
Key Features:
- 5G Ready*
- 3 dBi gain across lower bands 698-960 MHz
- 5 dBi gain across upper bands 1710-2700 MHz
- Ruggedised construction for Australian conditions
- Flexible enough to be roof gutter or mirror mounted
- Supplied with 4m of PT240 LSHF ultraflex cable with a pre-fitted SMA male connector
- Ideal antenna for the CEL-FI R41 vehicle repeater
- 40cm in height
* 5G via Dynamic Spectrum Sharing (DSS) on compatible repeaters including the CEL-FI R41.
Wideband Frequency Range
Operating across a wide frequency range from 698 MHz to 2700 MHz the Blackhawk 4G Trucker Mini Antenna ensures connectivity for various network bands making it suitable for 4G 3G and other cellular applications. With 3 dBi gain on the lower bands and 5 dBi gain on the higher bands this antenna guarantees optimal signal performance whether you're stationary or on the move.
Versatile Mounting Options
This antenna is designed for versatility allowing easy mounting on the roof gutter or mirror of any vehicle. Supplied with an L-bracket and a 4-metre LMR240 UltraFlex cable it ensures quick installation and a stable connection for mobile applications. The compact design ensures clearance under car park height restrictions adding convenience for everyday use.
Built for Harsh Conditions
Engineered to withstand extreme environments the Blackhawk Trucker Mini Antenna is constructed from durable glass and steel. With an operating temperature range of -40 °C to 65 °C it offers reliable performance in all weather conditions ensuring you stay connected regardless of the elements.
Ideal for Cel-Fi GO Repeater Systems
This antenna is the perfect companion for Cel-Fi GO Mobile vehicle repeater systems. The Blackhawk Trucker Mini maximises the coverage area ensuring you maintain a strong and reliable connection even in remote locations. It provides consistent communication whether you're off-road or travelling in low-signal areas.
Superior Beamwidth and Coverage
With a vertical beam width of 60° and a 360° horizontal beam width the Blackhawk 4G Trucker Mini Antenna delivers comprehensive coverage making it perfect for vehicular use. This ensures minimal signal dropouts regardless of your vehicle's orientation or movement.
Lightweight and Easy to Install
Weighing just 0.50 kg and with a diameter of 16 mm this antenna is both lightweight and compact. Its small footprint allows easy installation without compromising on performance. The SMA Male connector ensures compatibility with a wide range of devices making this antenna a versatile choice for mobile communications.
Specification:
| Category | Specification | Details |
|---|---|---|
| Model Number | VCOL-6927.N2 | Blackhawk 4G Trucker Mini Antenna |
| Frequency Range | 698 to 960 MHz 1710 to 2700 MHz | Wideband coverage for 4G/LTE |
| Gain | 3 dBi (698-960 MHz) | Lower frequency bands |
| 5 dBi (1710-2700 MHz) | Higher frequency bands | |
| VSWR | ≤ 2.0 | Efficient signal transmission |
| Vertical Beamwidth | 60° | Wide vertical coverage |
| Horizontal Beamwidth | 360° | Omnidirectional coverage |
| Input Impedance | 50 Ω | Standard impedance for antennas |
| Max Input Power | 100 W | High power handling capacity |
| Connector | SMA Male | Compatible with various devices |
| Dimensions | 400 × 16 mm | Length x Diameter |
| Weight | 0.50 kg | - |
| Operating Temperature | -40 °C to +65 °C | Suitable for extreme conditions |
| Material | Glass/Steel | Durable construction |
| Colour | Black | - |
| Mounting Pole Diameter | 32.5 mm | Fits various mounting poles |
| Cable | LMR240 UltraFlex 4 m | Includes high-performance cable |
@11/24
Blackhawk 4G Wideband LPDA Antenna 698 to 2700 MHz + 10m Cable N Male to SMA Male
Blackhawk 4G Wideband LPDA Antenna 698 to 2700 MHz + 10m Cable N Male to SMA Male
Description::
A Versatile Antenna that Provides a Cost-effective Solution for Improving Wireless Signal
Key features
- 10/11 dBi Gain: Strong signal reception across lower and upper frequency bands.
- Compact Design: Lightweight and easy to install for temporary or traveling setups.
- Versatile Mounting: Includes mounting clamp and pole-mounting options for flexible installation.
- 10m PT240 Cable: Supplied with N Male to SMA Male connectors for reliable connectivity.
- Weather-Resistant: Built with durable aluminum and ABS suitable for harsh conditions.
- Wide Temperature Range: Operates in temperatures from -40°C to +65°C with a wind resistance of up to 210 km/h.
*Note: This product comes with a 10m cable included.
Specification:
Specifications
| Electrical Specifications | |
|---|---|
| Frequency Range | 700-960 MHz / 1710-2600 MHz |
| Input Impedance | 50 Ω |
| Gain | 10 / 11 dB |
| VSWR | ≤ 2.0 / ≤ 1 |
| Polarisation | Vertical |
| Horizontal Beamwidth | 70° |
| Vertical Beamwidth | 50° |
| Maximum Input Power | 50 W |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
|---|---|
| Dimensions | 450 x 210 x 65 mm |
| Weight | 1.1 kg |
| Operating Temperature | -40°C – +65°C |
| Connector | 1 x N-Female |
| Material | Aluminium and ABS |
| Antenna Colour | White |
| Mounting Pole | 38 – 52 mm |
| Rated Wind Velocity | 210 km/h |
@15/30
Blackhawk ANT-BH-00030 4G/*5Gᅠ Trucker Edge Compact LITE Antenna 700 to 2200 MHz SMA Male 60cm high.
The Blackhawk 4G Trucker Edge Compact LITE Antenna offers 698-2200 MHz coverage 4-5 dBi gain and versatile mounting for reliable durable connectivity.
The Blackhawk Trucker EDGE Compact Antenna ヨ 4/6dBi is ideal for all carrier bands Telstra Optus and Vodafone 4G.
The Blackhawk 4G Trucker Edge Compact LITE Antenna 700 to 2200 MHz SMA Male is designed to meet the demands of 4G networks across Australia. With a frequency range of 698 to 2200 MHz this antenna ensures reliable voice and data communication making it ideal for commercial and industrial applications where dependable connectivity is crucial.
Key Features:
- 698-960 MHz and 1710-2170 MHz Frequency Range
- 4 dBi to 5 dBi Gain
- ?2.0 VSWR
- Vertical polarisation.
- 360ᄚ Horizontal Beamwidth
- 48ᄚ Vertical Beamwidth
- 50 Ohms Input Impedance
- 50W max. Power Handling
- Copper Reflector
- Fibreglass Radome
- 60cm in height
Optimised Design for Durability
Featuring a sleek 60 cm design the Trucker Edge Compact LITE is lighter than its counterpart weighing only 1.2 kg. Its streamlined barrel design not only reduces weight but also minimises vibrations making it suitable for use on corrugated roads and in harsh environments. This design improvement enhances durability and reduces potential damage during transit.
Advanced Signal Gain
The antenna provides a gain of 4 dBi in the lower frequency range (698-960 MHz) and 5 dBi in the higher range (1710-2200 MHz). This gain enhances signal strength ensuring better coverage and connectivity for your 4G network needs.
Versatile Mounting Options
Equipped with an SMA-Male connector and a 4.5-meter coax cable the Blackhawk Trucker Edge Compact LITE offers flexible installation options. It can be mounted on a car bonnet or bull bar making it adaptable to various vehicle types and ensuring optimal signal reception.
Crafted for Extreme Conditions
Built to withstand extreme conditions this antenna features a rugged construction that is capable of handling temperatures from -40 ᄚC to +65 ᄚC. The durable copper reflector and fibreglass radome ensure the antenna performs reliably in harsh environments.
Comprehensive Coverage
With a vertical beam width of 48ᄚ and a horizontal beam width of 360ᄚ the Trucker Edge Compact LITE provides broad and even signal coverage. This wide beam width ensures consistent performance regardless of the direction of the signal source.
Enhanced Safety Features
The antenna is designed with built-in lightning protection and operates at a maximum power of 50 watts. This feature ensures that your equipment remains safe from electrical surges and extends the longevity of your antenna in demanding conditions.
Blackhawk ANT-BH-OM-202TB-2 Trucker Edge Antenna 698 To 2200 MHz 95cm high.
The Blackhawk4G/*5G Trucker Edge Antenna 698 to 2200 MHz SMA Male offers 6 dBi gain a durable fibreglass build and easy installation for vehicles.
The Blackhawk4G/*5G Trucker Edge Antenna 698 to 2200 MHz SMA Male is a high-performance solution for those needing reliable connectivity while on the move. It is specifically designed for vehicle-mounted applications providing a seamless experience across 4G/*5G networks including preparations for the 5G NR850. This antenna is ideal for use in Australia's varied terrains offering stable performance in both flat and hilly regions.
Key Features:
- 5G Ready*
- Optimum 6 dBi gain for flat and hilly areas
- Extra heavy-duty stainless steel spring
- High-vibration PTL-240 Ultra-Flex cabling
- 4.5 metres of cable with an industry-standard SMA Male connector
- 95cm in height
*5G via Dynamic Spectrum Sharing (DSS) on compatible repeaters including the CEL-FI R41.
Superior Design for Rugged Conditions
Built with a robust fibreglass radome and a stainless-steel spring the Trucker Edge Antenna is designed to handle harsh environments. The antennaメs sturdy construction ensures optimal performance even in extreme conditions making it suitable for long-term use in mining industrial and transport industries. The 950 mm height ensures excellent signal capture while the tapered design helps minimise damage from wind or debris.
Optimal Gain for Improved Connectivity
With a gain of 6 dBi the Blackhawk Trucker Edge Antenna delivers enhanced performance in areas with poor cellular reception. Whether you're navigating remote highways or moving through rugged landscapes the antenna provides consistent coverage. It works across frequencies from 698 to 2200 MHz ensuring compatibility with major Australian networks and delivering stable voice and data connections.
Ready for Immediate Use
The Blackhawk Trucker Edge Antenna is supplied pre-terminated with a 4.5-metre PTL-240 Ultra-Flex cable and an SMA male connector making it easy to install right out of the box. The ultra-flex cable offers low signal loss ensuring high-quality transmission especially important in high-vibration environments such as vehicles and heavy machinery.
Future-Proof Performance
In addition to 3G and 4G support this antenna is ready for the future with 5G NR850 compatibility. Its durable design and reliable performance make it an excellent choice for long-term vehicle and industrial applications ensuring your communication devices remain effective as technology evolves.
Ease of Installation
Designed for bull bar mounting the Trucker Edge antenna includes an extra-heavy-duty stainless steel bell spring making it ideal for installations on vehicles used in off-road or rugged environments. The antenna's 16 mm stud allows for secure and straightforward installation on a wide range of vehicles.
Durability Across All Conditions
The Blackhawk Trucker Edge Antenna is designed to withstand extreme temperatures from -40 ᄚC to +65 ᄚC making it suitable for use across various Australian climates. Its UV-resistant radome ensures long-lasting performance even when exposed to intense sunlight for extended periods.
Blackhawk ANT-BH-OM-205B Blackhawk 4G Trucker Edge Compact Antenna 698 To 2200 MHz 68cm high.
Enhance mobile communication with Blackhawk 4G Trucker Edge Compact Antenna. Wide frequency range SMA Male connector. Trust Blackhawk Antennas for reliable signal boost.
The Blackhawk Trucker EDGE Compact Antenna � 4/6dBi is ideal for all carrier bands Telstra Optus and Vodafone 4G/*5G.
Future-proof your vehicle installations with this high grade ruggedized Omni Trucker Antenna. This premium-grade cellular antenna will satisfy 3G and 4G capabilities for all the major networks in Australia and can be used for commercial and industrial 3G and 4G applications.
Trucker EDGE Compact Features:
- 5G Ready*
- 4 dBi gain across lower bands 698-960 MHz
- 6 dBi gain across upper bands 1710-2170 MHz
- Can be mounted directly on a bullbar
- Suitable for all mobile carriers
- Included is 4 metres of LMR240 Ultra Flex cable fitted with SMA/M connector
- Made of ruggedized fibreglass to withstand 210km/h winds
- Bracket additional
- 68cm in height
*5G via Dynamic Spectrum Sharing (DSS) on compatible repeaters including the CEL-FI R41.
The Blackhawk Omni Trucker Edge Compact at 68cm will provide the perfect solution for voice and data applications where high gain antennas are required while on the move. Combine with a CEL-FI ROAM in your vehicle to never be out of contact when away from home.
Specifications
ELECTRICAL SPECIFICATIONS
| Frequency Range | 698-960 MHz / 1710-2170 MHz |
| Input Impedance | 50 ? |
| Peak Gain | 4 / 6 dBi |
| VSWR | ?2.0:1 /�?2.0:1 |
| Polarisation | Vertical linear |
| Horizontal Beamwidth | 360� (omnidirectional) |
| Vertical Beamwidth | 48 / 23� |
| Maximum Input Power | 50 W |
MECHANICAL SPECIFICATIONS
| Input Connector | SMA Male |
| Cable | 4 m PT240 cable |
| Lightning Protection | DC Ground |
| Antenna Construction | Fibreglass radome heavy duty spring base |
| Dimensions | 680 x �20 mm |
| Weight | 1.5 kg |
| Rated Wind Velocity | 210 km/h |
| Operating Temperature | -40 to +65�C |
Blackhawk ANT-BH-OM-C Ceiling Dome 698-4000 2/5dBi Antenna -150dBc PIM
Blackhawk ANT-BH-OM-C Ceiling Dome 698-4000 2/5dBi Antenna -150dBc PIM
Blackhawk ANT-BH-OM-C Ceiling Dome 698-4000 2/5dBi Antenna -150dBc PIM
This is the ideal indoor antenna for Cel-Fi repeater systems. Indoor dome antennas are designed to be mounted to the ceiling of your building to provide consistently distributed mobile phone service from your Cel-Fi repeater/booster. The antenna is compact with a visually unobtrusive design similar to a smoke alarm.
The Blackhawk Omni Ceiling Antenna will provide the perfect solution for voice and data applications. Perfect for repeater applications that require a 360� beamwidth for complete internal coverage.
FEATURES
- 2 dBi gain across lower bands 698-960 MHz
- 5 dBi gain across upper bands 1710-4000 MHz
- ABS plastic and aluminum construction
- Threaded bulkhead mount for ceiling installation
- Short cable tail with N female connector
- Ideal for Cel-Fi GO repeater marine/ caravan applications
Specifications:
| Model Number | ANT-BH-OM-C | Powertec 4G-5G Ceiling Dome Antenna |
| Frequency Range | 698 to 960 MHz 1710 to 2700 MHz 3300 to 4000 MHz | Wideband coverage for 4G and 5G |
| Gain | 2.0 dBi (698-960 MHz) | Low frequency band |
| 5.0 dBi (1710-2700 MHz) | Mid-frequency band | |
| Gain | 5.5 dBi (3300-4000 MHz) | High frequency band |
| VSWR | ? 1.8 (698-960 MHz) | Efficient signal transmission for low frequencies |
| ? 1.5 (1710-2700 MHz 3300-4000 MHz) | Efficient signal transmission for mid and high frequencies | |
| Polarisation | Vertical | Standard vertical orientation |
| PIM 3rd Order | ? -150 dBc (2�20W) | Low intermodulation interference |
| Horizontal Beamwidth | 360� | Omnidirectional coverage |
| Vertical Beamwidth | 85� (698-960 MHz) | Wide vertical coverage for low frequencies |
| 54� (1710-2700 MHz) | Moderate vertical coverage for mid-frequencies | |
| 28� (3300-4000 MHz) | Narrow vertical coverage for high frequencies | |
| Input Impedance | 50 ? | Standard impedance for antennas |
| Max Input Power | 50 W | High power handling capacity |
| Connector | N Female | 4.3-10 DIN Female | Versatile connector options |
| Dimensions | �186 x 86 mm | Diameter x Height |
| Weight | 0.25 kg | - |
| Reflector Material | Aluminium | Durable and lightweight |
| Radome Material | ABS (UV Stabilised) | Durable and weather-resistant |
Blackhawk ANT-BH-OM-C Ceiling Dome 698-4000 2/5dBi Antenna with 6Mts cable
Blackhawk ANT-BH-OM-C Ceiling Dome 698-4000 2/5dBi Antenna with 6Mts cable
Blackhawk ANT-BH-OM-C Ceiling Dome 698-4000 2/5dBi Antenna - 6Mtrs cable Terminated SMA(M) to connect direct to Cel-Fi unit
This is the ideal indoor antenna for Cel-Fi repeater systems. Indoor dome antennas are designed to be mounted to the ceiling of your building to provide consistently distributed mobile phone service from your Cel-Fi repeater/booster. The antenna is compact with a visually unobtrusive design similar to a smoke alarm.
The Blackhawk Omni Ceiling Antenna will provide the perfect solution for voice and data applications. Perfect for repeater applications that require a 360� beamwidth for complete internal coverage.
FEATURES
- 2 dBi gain across lower bands 698-960 MHz
- 5 dBi gain across upper bands 1710-4000 MHz
- ABS plastic and aluminum construction
- Threaded bulkhead mount for ceiling installation
- Short cable tail with N female connector
- Ideal for Cel-Fi GO repeater marine/ caravan applications
- includes 6mtr cable N(Male) to SMA (male)
Specifications:
| Model Number | ANT-BH-OM-C | Powertec 4G-5G Ceiling Dome Antenna |
| Frequency Range | 698 to 960 MHz 1710 to 2700 MHz 3300 to 4000 MHz | Wideband coverage for 4G and 5G |
| Gain | 2.0 dBi (698-960 MHz) | Low frequency band |
| 5.0 dBi (1710-2700 MHz) | Mid-frequency band | |
| Gain | 5.5 dBi (3300-4000 MHz) | High frequency band |
| VSWR | ? 1.8 (698-960 MHz) | Efficient signal transmission for low frequencies |
| ? 1.5 (1710-2700 MHz 3300-4000 MHz) | Efficient signal transmission for mid and high frequencies | |
| Polarisation | Vertical | Standard vertical orientation |
| PIM 3rd Order | ? -150 dBc (2�20W) | Low intermodulation interference |
| Horizontal Beamwidth | 360� | Omnidirectional coverage |
| Vertical Beamwidth | 85� (698-960 MHz) | Wide vertical coverage for low frequencies |
| 54� (1710-2700 MHz) | Moderate vertical coverage for mid-frequencies | |
| 28� (3300-4000 MHz) | Narrow vertical coverage for high frequencies | |
| Input Impedance | 50 ? | Standard impedance for antennas |
| Max Input Power | 50 W | High power handling capacity |
| Connector | N Female | 4.3-10 DIN Female | Versatile connector options |
| Dimensions | �186 x 86 mm | Diameter x Height |
| Weight | 0.25 kg | - |
| Reflector Material | Aluminium | Durable and lightweight |
| Radome Material | ABS (UV Stabilised) | Durable and weather-resistant |
BLACKHAWK LPDA Outdoor mobile signal NextG 3G 4G 4GX external antenna 698-2700MH
$329.00
Unit price perBLACKHAWK LPDA Outdoor mobile signal NextG 3G 4G 4GX external antenna 698-2700MH
$329.00
Unit price perFEATURES
- 12 dBi gain across lower bands 698-960 MHz
- 14 dBi gain across bands 1710-2700 MHz
- 12 dBi gain across upper bands 3300-4000 MHz
- Ruggedised construction for Australian conditions
- Fully welded, powder coat aluminium design
- Stainless steel mounting clamp included
- 30 cm tail with pre-terminated N Female connector
- Ideal for high-speed 3G and 4G LTE applications.
- Ideal for Telstra Next-G and 4GX networks, Optus, and Vodafone 3G/4G & 5G
Ideal for Telstra Next-G and 4GX networks, Optus, and Vodafone 3G/4G.
Operating on all 3G and 4G frequencies in Australia and abroad, this high grade antenna can be used in a range of residential, commercial, and industrial mobile broadband applications on any mobile network. This is the ideal external antenna for Cel-Fi repeater systems.
The Blackhawk Wideband LPDA Antenna provides an ideal solution for 3G / 4G voice and data applications. With the rollout of new 3G and 4G frequencies such as 700 MHz 4GX and 2600 MHz 4G, traditional Yagi antennas just haven't been able to keep up. LPDA antennas allow a single antenna to cover all frequencies with the high gain of a Yagi antenna that rural and remote areas demand. This one antenna can be used on any mobile phone network in Australia, in any area without worrying about compatibility.
A Log Periodic Dipole Antenna, or LPDA for short, is a clever antenna design that provides exceptionally wideband performance by phasing a series of elements together, much like an ordinary yagi but with each successive element of a smaller (or larger) length. The result of this clever engineering is an antenna that holds high gain, with good tuning, across the entire cellular frequency range.
Notes: In order to boost radio signal the following components are required: Antenna, antenna mount, booster and cable. The antenna and booster must operate in the frequency band of the signal. Signal cable feeds signal from antenna to booster.
-
ELECTRICAL SPECIFICATIONS
Frequency Range 698-960 MHz / 1710-2700 MHz Input Impedance 50 Ω Peak Gain 11 / 12 dBi VSWR ≤2.5:1 / ≤1.8:1 Polarisation Vertical, linear Horizontal Beamwidth 55 / 42° Vertical Beamwidth 46 / 34° Maximum Input Power 50 W MECHANICAL SPECIFICATIONS
Input Connector N Female Cable 30 cm cable tail Lightning Protection DC Ground Radiator Material Fully welded aluminium, black powder coat Mounting Stainless Steel, pole mount Ø30-50 mm Dimensions 1240 x 200 x 60 mm Packing Dimensions 1290 x 210 x 90 mm Weight 2.2 kg Rated Wind Velocity 192 km/h Operating Temperature -40 to +65°C
Blackhawk Marine Cellular Antenna 698-2700 with Stainless Steel Adjustable Mount
Blackhawk Marine Cellular Antenna 698-2700 with Stainless Steel Adjustable Mount
@34/62
Blackhawk Marine Cellular Antenna 698-2700MHz 7dBi with Nylon Adjustable Mount
Blackhawk Marine Cellular Antenna 698-2700MHz 7dBi with Nylon Adjustable Mount
@29/53
Blackhawk Marine Cellular Antenna 698-2700MHz 7dBi with Stainless Steel Fixed Mount
Blackhawk Marine Cellular Antenna 698-2700MHz 7dBi with Stainless Steel Fixed Mount
@33/60
Blackhawk Marine Cellular Antenna 698-2700MHz 7dBi with Stainless Steel Rail Mount
Blackhawk Marine Cellular Antenna 698-2700MHz 7dBi with Stainless Steel Rail Mount
@22/42
Provides a 3dBi gain for 698-2700 MHz
The ANT-BH-SF-100 screw mount Shark Fin Transit Antenna covers GPS/4G/WiFi requirements and is designed for maximum performance and versatility for telematics applications, emergency service vehicles fleet monitoring and asset tracking.
Features:
• Supports 698 – 2700 MHz suitable for all mobile carriers
• IP67 rated
• RoHS Compliant
• Mounting includes thread bolt mount and permanent adhesive
• Antenna has dimensions 83x54x83mm
ELECTRICAL SPECIFICATIONS
Frequency Range: GPS - 1575.42 MHz ±3 MHz / WiFi - 2400-2438 / 5700-5800 MHz / LTE - 698-960 MHz / 1710-2700 MHz
Impedance: 50 Ω
VSWR: LTE - 2.0: 1 / GPS - 2.0:1
Gain: GPS - 5 dBi / LTE - 3 dBi / WiFi - 3 dBi
Polarisation WiFi: GPS - RHCP / LTE - Linear / WiFi - Linear
Max Input Power: 50W
MECHANICAL SPECIFICATIONS
Dimensions: 85 x 54 x 83 mm
Weight: 180g
Operating Temperature: -40°C to +85°C
Connector: GPS: TNC-Female / LTE: N-Female / WiFi: N-Female
Cable: GPS: RG174 250mm / 3G/4G: RG174 300mm / WiFi: RG174 350mm
Material: ABS
Antenna Colour: Black
RoHS Compliant: Yes
Waterproof: IP67
-
FEATURES
- 10 dBi gain across lower bands 698-960 MHz
- 11 dBi gain across upper bands 1710-2700 MHz
- Lightweight, compact design
- Mounting clamp included
- 30 cm tail with pre-terminated N Female connector
- Optional: Supplied with 10 m of RG58 cable with SMA Male connectors
- Great cost effective antenna.
The Blackhawk wideband antenna is a fantastic little antenna providing good performance with a lightweight, low-cost design. There's plenty of situations where a big, solid metal antenna is necessary, but also plenty where something quick and small can be just as useful. This antenna is great for areas where indoor signal is weak, and only a simple antenna on the roof is enough to give a fantastic improvement.
The antenna is simple and effective, it might not last as long as a fully welded yagi, or our Backhawk LPDA, but it's a great antenna for temporary installations or those travelling who need something compact.
Mounting is made simple with a mast down-tilt bracket and U-Bolts. This enables you to mount the antenna on a flat surface or a pole.
ELECTRICAL SPECIFICATIONS
| Frequency Range | 698-960 MHz / 1710-2700 MHz |
| Input Impedance | 50 Ω |
| Gain | 10 / 11 dB |
| VSWR | ≤ 2.0 / ≤ 1 |
| Polarisation | Vertical |
| Horizontal Beamwidth | 70° |
| Vertical Beamwidth | 50° |
| Maximum Input Power | 50 W |
| Lightning Protection | DC Ground |
MECHANICAL SPECIFICATIONS
| Dimensions | 450 x 210 x 65 mm |
| Weight | 1.1kg |
| Operating Temperature | -40°C - +65° |
| Connector | 1 x N-Female |
| Material | Aluminum and ABS |
| Dimensions | 442 x 205 x 37 mm |
| Antenna Colour | White |
| Mounting Pole | 38 - 52 mm |
| Rated Wind Velocity | 210km/h |
Cable Optional: 6m/10m/15m/20m
LSFH-240 CABLE N MALE – SMA MALE
This cable is low smoke halogen, to reduce the amount of toxic and corrosive gas emitted during combustion or fire.
Choose your own cable length: 6m, 10m, 15m, 20m.
- Ideal for connecting Blackhawk antennas to any Cel-Fi units.
About BlueAnt Pump Air EPIC True Wireless Earbuds - Black
Experience audio perfection with BlueAnt Pump Air EPIC True Wireless Earbuds! 40 hours playtime 6 mics wireless charging Active Noise Cancellation and Advanced Transparency for thumping bass and crystal clear highs. Your sound your style.
Specifications:
- Playtime: Up to 40 Hours (With Case)
- Water Resistant Rating: IP54
- Bluetooth Version: 5.3
- Driver Size: 8mm
- Active Noise Cancellation: Up to 35dB
- Weight: 4g per earbud
Features:
- Up to 40 Hours playtime (With Case)
- Simple one touch controls
- 35dB Active Noise Cancellation - Block out the world
- Feel the Bass - 8mm HD drivers deliver bass you can feel and highs that shine
- Perfect Fit - With three sizes of ear tips & three sizes of stabilizers the Epic provides the perfect fit
- IP54 rated water & sweatproof
- Wireless Charging Case
- Rapid Charging
- Siri / Google Assistant Integration
- 6 Built-in Microphones for Handsfree calling
- Simple Setup
What's in the box?
- 1 x BlueAnt Pump Air EPIC True Wireless Earbuds
- 1 x Charging Cable
- 3 x Sizes of ComfortSeal Tips
- 3 x Sizes of Stabilizers
- 1 x User Manual
About BlueAnt Pump Air EPIC True Wireless Earbuds - White
Experience audio perfection with BlueAnt Pump Air EPIC True Wireless Earbuds! 40 hours playtime 6 mics wireless charging Active Noise Cancellation and Advanced Transparency for thumping bass and crystal clear highs. Your sound your style.
Specifications:
- Playtime: Up to 40 Hours (With Case)
- Water Resistant Rating: IP54
- Bluetooth Version: 5.3
- Driver Size: 8mm
- Active Noise Cancellation: Up to 35dB
- Weight: 4g per earbud
Features:
- Up to 40 Hours playtime (With Case)
- Simple one touch controls
- 35dB Active Noise Cancellation - Block out the world
- Feel the Bass - 8mm HD drivers deliver bass you can feel and highs that shine
- Perfect Fit - With three sizes of ear tips & three sizes of stabilizers the Epic provides the perfect fit
- IP54 rated water & sweatproof
- Wireless Charging Case
- Rapid Charging
- Siri / Google Assistant Integration
- 6 Built-in Microphones for Handsfree calling
- Simple Setup
What's in the box?
- 1 x BlueAnt Pump Air EPIC True Wireless Earbuds
- 1 x Charging Cable
- 3 x Sizes of ComfortSeal Tips
- 3 x Sizes of Stabilizers
- 1 x User Manual
About BlueAnt Pump Air Lite 2 True Wireless Earbuds - Black
Experience music like never before with Pump Air Lite 2 earbuds. Touch-free controls for calls & music bass-rich audio ENC for crystal-clear calls sweatproof & up to 26-hour battery life. Get the perfect fit with the Comfortseal ear-tips.
Specifications:
- Headphones type: In-ear wireless
- Driver Size: 7mm
- Noise-cancelling: Yes
- Built-in microphone: Yes
- Bluetooth Version: 5.2
- Battery life: Up to 6 Hours (26 Hours Total with Case)
- Manufacturers warranty: 1 Year
Features:
- HD Audio with 7mm Drivers
- Built-in Microphones
- Bluetooth 5.2
- Siri & Google Assistant integration
- Get the perfect fit with 3 Sizes of ComfortSeal Tips
- 26 Hours of playtime (With Case)
- Expertly tuned by studio engineers
- Perfect for Gym or your daily commute
- IP55 Water Resistant
- Sweatproof
- Handsfree Calling
- Ultra-Lightweight at 4g per Earbud
- USB-C Rapid Charging
- Small & Discreet design
- Environmental Noise Cancellation
What's in the Box?:
- 1 x BlueAnt Pump Air Lite 2 True Wireless Earbuds
- 1 x BlueAnt Pump Air Lite 2 Charging Case
- 1 x Charging Cable
- 1 x User Manual
- 3 x Sizes of ComfortSeal Tips
