Sort by:
@0/57
@0/56
Warranty Period: 5-Year
@0/56
@0/62
@13/13
@0/42
@35/29
Device
*Outdoor 5G Gateway / Router
Dual *Nano SI *PoE powered *
Omada-managed
Cellular – 5G NR
* Bands: n1 / n3 / n5 / n7 / n8 / n20 / n26 / n28 / n38 / n40 / n41 / n75 / n76 / n77 / n78 *
Frequencies: 700 / 800 / 850 / 900 / 1500 / 1800 / 2100 / 2300 / 2500 / 2600 / 3500 / 3700 MHz
* SA:
7.01 Gbps ↓ / 1.25 Gbps ↑
*NSA: 4.5 Gbps ↓ / 730 Mbps ↑
Cellular – 4G LTE
* FDD: B1 / B3 / B5 / B7 / B8 / B20 / B26 / B28 / B32
*TDD: B38 / B40 / B41 / B42 / B43 *
Speed: 1.6 Gbps ↓ / 211 Mbps ↑
Cellular – 3G *
WCDMA: B1 / B5 / B8
SIM
*1 × Dual Nano SIM slot *
Failover supported
Ethernet
*1 × 2.5G RJ45
*10 / 100 / 1000 / 2500 Mbps
*PoE:
*802.3at (42–57 V 0.6 A) *
Passive 48 V
Wireless (Local)
* 2.4 GHz only
* 802.11 b / g / n
* 150 Mbps max *
WPA / WPA2-Personal
* 1 SSID
*TX power control *
Auto channel selection Routing / Switching
*Static routing *
OSPF (Standalone) *
Bridge VLAN
* 802.1Q VLAN *
Multi-Net interfaces
NAT / Firewall *
Multi-Net NAT *
Virtual server *
Port triggering *
NAT-DMZ
*ALG: FTP / SIP / IPSec / PPTP / H.323 *
UPnP
*Stateful ACL Storage / Memory
*4 GB eMMC
*2 GB LPDDR4x Power
Max consumption: *15.3 W Physical
Dimensions: *183 × 110 × 36 mm
* Wall / pole / window mount *
Waterproof kit included
Warranty Period: 3-Year
@0/98
@0/40
Warranty Period: 5-Year
@0/40
@0/58
Warranty Period: 5-Year
@0/43
@0/48
@15/14
@22/22
HARDWARE FEATURES
Interface * 5× 2.5 Gbps RJ45 Ports (4× 802.3af/at/bt-compliant PoE++) * 1× 10 Gbps SFP+ Slot * Auto-Negotiation/Auto MDI/MDIX Fan Quantity *Fanless Installation * Desktop * Wall Mount Physical Security Lock *√ Power Supply *DC Power Adapter (Output: 53.5 VDC / 2.43 A) PoE Ports (RJ45) * Standard: 802.3af/at/bt PoE++ compliant * PoE Ports: 4 Ports * PoE Budget: 120W available for all PoE++ ports 90W max per port * Fast PoE & Perpetual PoE * PoE Auto Recovery‡ Dimensions ( W x D x H ) *8.2 × 5.0 × 1.0 in (209 × 126 × 26 mm) Surge Protection *±6 kV
PERFORMANCE
Packet Buffer Memory *640 KB Jumbo Frame *10 KB Switching Capacity *45 Gbps Packet Forwarding Rate *33.48 Mpps MAC Address Table *16K
SOFTWARE FEATURES
Quality of Service * Port-based/802.1p/DSCP QoS * 8 Priority Queues * Priority Schedule Mode - WRR (Weighted Round Robin) * Queue Weight Config * Bandwidth Control - Port-Based Rating Limit * Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control△ L2 Features * Static Link Aggregation * Loop Prevention / Loopback Detection * Flow Control - 802.3x Flow Control * Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both * Port Statistics - Port Mirror Status - Traffic Statistics * 802.1ab LLDP L2 Multicast * IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave VLAN * MTU VLAN * Port-Based VLAN * 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID Transmission Method *Store-And-Forward
Warranty Period: 5-Year
@0/42
@17/16
@26/23
