Description
QUBINO Z-Wave Flush 2 Relay DC
Quick Overview
QUBINO Z-Wave Flush 2 Relay DC is a Z-Wave module for switching on/off one or two electrical devices (e.g. light fan etc …). The module can be controlled either through Z-wave network or through the wall switch manually.
This module is designed to be mounted behind a traditional wall switch. The module measures power consumption of load and supports connection of digital temperature sensor. It is designed to act as a repeater in order to improve the range and stability of the Z-Wave network.
Supported switches
Module supports mono-stable switches (push button) and bi-stable switches. The module is factory set to operate with bi-stable switches.
Product Details
• Compatible with any Z-Wave Controller.
• Dimensions (W x H x D) 41 8 x 36 8 x 15 4mm
• Power monitoring accuracy P=5-50W +/-3W; P˃50W +/-3%;
• Digital temperature sensor range (sensor must be ordered separately) -50 ~ 125°C
• Support for the connection of digital temperature sensor (optional part)
• 2 binary inputs offer the option to connect additional devices such as sensors switches/push buttons etc …
Product Support
Configuring Z-Wave Devices:
Z-Wave devices often have several configurable parameters which you can change using your Vera’s user interface. These parameters can include things such as the length of time a Z-Wave siren remains active for or the type of manual switch connected to a Z-Wave light controller.
Every available configurable parameter is listed in your device’s user manual. In most cases your device’s default parameters will be suitable to your needs however sometimes it may be necessary to adjust them to optimally use your device. A guide to configuring Z-Wave devices with Vera UI7 is available in the Manuals section.
Strengthens Z-Wave Connectivity
The smart relay module has been designed to work as a Z-Wave repeater thereby providing you the flexibility to extend the range of your Z-Wave network.
The QUBINO double switch is Z-Wave Plus Certified. Z-Wave Plus (5th Generation Z-Wave) offers a lot of new features including increased range extended battery life and Over The Air upgrading (OTA). Take a look at our “What is Z-Wave Plus” guide for more information.
Note!
Do not connect the module to loads exceeding recommended values. Connect the module only in accordance to the manual and diagrams below. Use only quilified electrician!
Manuals:
⇒ QUBINO Z-Wave Double Switch Installation Manual
⇒ Z-Wave Fan Control Solution(250KB)
⇒ Guide to Configuring Z-Wave Devices with Vera UI7 (Size: 435 kB)
Videos / YouTube:
Technical Specifications
Product Name |
Z-Wave Dbl Switch |
Powered by |
24V DC or 30V DC |
Operation Range |
30m |
Max Load |
2300W (24VDC) |
Radio frequency |
921.42 MHz (AU/NZ Z-Wave) |
Power Consumption |
0 4W |
Operation temperature |
-10 -+40 C* |
| Measured temperature range | 0 5o C (within 0o C – 40o C range) (optional sensor) |
Temperature measuring accuracy |
0 5 C |
Housing |
ABS |
Dimensions (W x H x D) |
41.8 x 36.8 x 15.4 mm |
@10/29
Description
Quick Overview
Z-Wave™ shutter control with power measurement 10 A per channel
Automate and remotely control the position of roller shutters blinds windows awnings pool covers and other devices powered by bi-directional AC motors.
- Control the tilt position (angle) of the venetian blind slats
- Supports push-buttons/momentary switches and toggle switches
- Power metering
- Extremely low power consumption: < 0.3 W
- Z-Wave frequency band: 868.4 MHz (CEPT countries)
- Latest technology: Z-Wave 800 Series
- Automatic set-up with SmartStart
- Security 2 Authenticated for the highest level of security
- Over-the-air firmware updates
- Works with Z-Wave-certified gateways and over 4 000 Z-Wave devices
*A gateway (smart hub) is not included. A gateway (smart hub) is required for the configuration of the device.
Works with any Z-Wave gateway
Wave Shutter is retrofit and designed to fit behind switches/push-buttons instantly transforming them into smart ones. Once installed include the device in your Z-Wave network (Z-Wave gateway is required) and control connected appliances from anywhere using your smartphone or tablet. Shelly Qubino devices work with over 4000 Z-Wave certified devices and gateway
Shelly Qubino works on Z-Wave
By using Z-Wave smart home products can seamlessly communicate with each other regardless of their brand or platform thanks to a centralized smart hub! Shelly Qubino devices work on the latest Z-Wave chip generation (S800) one of the most popular standardized technologies for smart homes in the world.
*Z-Wave devices have specific requirements in order to function correctly such as the necessity to use a supported Z-Wave hub. For more information please visit the official Z-Wave website: www.z-wave.com
Manuals:
⇒ Shelly Z-Wave Qubino Wave Shutter
⇒ Z-Wave Fan Control Solution(250KB)
⇒ Guide to Configuring Z-Wave Devices with Vera UI7 (Size: 435 kB)
Videos / YouTube:
Technical Specifications
| Power supply | 110-240 V AC / 24 V DC +/-10% |
| Power consumption | < 0.3 W |
| Max. switching voltage AC | 240 V |
| Max. switching current AC | 110 A per channel |
| Max. switching voltage DC | 30 V |
| Max. switching current DC | 10 A |
| Overheating protection | Yes |
| Distance | Up to 40 m indoors (131 ft.) (depends on local condition) |
| Z-Wave® repeater | Yes |
| CPU | Z-Wave® S800 |
| Z-Wave® frequency bands | 868 4 MHz; 865 2 MHz; 869 0 MHz; 921 4 MHz; 908 4 MHz; 916 MHz; 919 8 MHz; 922 5 MHz; 919 7-921 7-923 7 MHz; 868 1 MHz; 920 9 MHz |
| Maximum radio frequency power transmitted in frequency band(s) |
< 25 mW |
| Size (H x W x D) | 37x42x16 ±0.5 mm / 1.46×1.65×0.63 ±0.02 in |
| Weight | 29 g / 1.02 oz. |
| Mounting | Wall console |
| Screw terminals max. torque | 0.4 Nm / 3.5 lbin |
| Conductor cross section | 0.5 to 1.5 mm² / 20 to 16 AWG |
| Conductor stripped length | 5 to 6 mm / 0.20 to 0.24 in |
| Shell material | Plastic |
| Ambient temperature | -20°C to 40°C / -5°F to 105°F |
| Humidity | 30% to 70% RH |
| Max. altitude | 2000 m / 6562 ft |
@7/25
Description
DINUY IT KNT 16 channel Switching Actuator
Quick Overview
DINUY IT KNT 016: 16-channel Switching Actuator or 8-channel Blinds/Shutters Actuator – Extremally Versatile 16 high load capacity channels 16A 23 Inputs: 16-Binary Inputs plus 7 Analog or Binary inputs Manual control per channel with LEDs 16 Logic Functions Centralized Control Scenes Time Function DIN-rail mounting 8 modules wide
KNX Multifunction Actuator that can work as: 16-channel Switching Actuator or 8-channel Blinds/Shutters Actuator. High load capacity with 16A built-in relays as well as a zero-crossing-point control which allows switching very high loads even capacitive type. Incorporate 23 Inputs: 16-Binary Inputs + 7-Binary/Analog Inputs.
These inputs can be independently parameterized through the ETS Software:
· Binary Input: allows the connection of a conventional voltage-free binary sensor or switch.
· Analog Input: allows the connection of a DINUY temperature probe (ST KNT 001 or ST KNT 002). Incorporates a front keypad for independent manual control of each output as well as status indicator LEDs. Allows to enable and configure up to 7 independent Heating and / or Cooling Thermostats. It incorporates 16 Logic Functions Centralized Control Scenes Time Function etc. Possibility of connecting different phases in each output channel. DIN-rail mounting 8 modules wide. Programming and commissioning via ETS5 or later versions.
Dimensions
Documents
Videos / YouTube:
⇒Introduction – Configuration – Demonstration
Logistic Data
Technical Specifications
| Product reference | IT KNT 016 |
| Power supply | 230VCA |
| Frequency (Hz) | 50/60 |
| Consumption | < 10mA |
| Output channels | 16 |
| Switching capacity (A) | 16 |
| Type of load | channels |
| LED lamps load (W) | 400 |
| Incandescent and Halogen 230V (W) | 3000 |
| 12V Halogen with electronic transformer (W) | 3000 |
| Halogen lamps with ferromagnetic trafo (W | 500 |
| Motores (VA) | 700 |
| Maximum current input 1/10VDC (mA) | 0 |
| Maximum Number of Equipments | 0 |
| Contacts | Voltage-free |
| Binary/Analogic Inputs | 23 |
| Installation | DIN Rail |
| Module number | 8 |
| Control | KNX Bus |
| Programming by | ETS5 o posterior |
| Compatible with | KNX |
| Connection terminals | Captive Screws |
| Cable section (mm2) | 6 |
| Minimum Storage Temperature (ºC) (min) | -25 |
| Maximum Storage Temperature (ºC) (max) | 55 |
| Minimum Working Temperature (ºC) (min) | -5 |
| Maximum Working Temperature (ºC) (max) | 45 |
| Protection Degree | IP20 UNE 20324 |
KNX for Every Kind of Project
KNX technology is perfect for high-end residential and light commercial installations offering incredible quality and automation options for installers and end-users.
KNX technology allows a broad range of home automation devices to communicate with each other even if they are from different manufacturers and can even be integrated with other automation systems.Ready to enjoy the full potential of a KNX smart automation?
@81/119
The DS-KAB11-D is a Video Intercom Housing from Hikvision. Stainless steel surface mount enclosure for Hikvision DS-KD8002-V series IP intercom door station.
The BC1C is a 100% wire-free rechargeable camera that delivers well-rounded home protection for up to 210 days on one single charge. It can be simply installed anywhere for enhanced security, inheriting EZVIZ’s core technologies of colour night vision, two-way talk, active defence and more.
BC1 Battery-Powered Camera Kit
Ultra-long battery life for year-round peace of mind.
Used together with a base Station, the BC1 wire-free camera delivers well-rounded home protection for up to a full year on one single charge. The BC1 inherits EZVIZ’s core technologies of colour night vision, two-way talk, active defence, and more, showcasing unparalleled usability in any household
1080p Video
7,800 mAh Rechargeable Lithium Battery
Built-in 32 GB eMMC storage
Color Ngiht Vision
IP66 Dust and Water Protection
Accurate Human Motion Detection
Two-Way Talk
Active Defense
Sopports 2.4GHz Wifi
H.265 Video Compression
Customizable Voice Alerts
Works with EZVIZ Solar Panel for battery charging
Capture sharp and detailed 1440p footage as you drive and conveniently use your voice to control its various functions with the practical and feature-rich Nextbase 522GW Dash Cam.
Redefining the possibilities of a Dash Cam
Ideal Camera Setup
The Nextbase 522GW Dash Cam comes with a 1440p forward-facing camera with a viewing angle of 140-degrees for crisp and vibrant recordings with exceptional coverage. It also comes with Photo Mode for added convenience.
For Your Convenience
Thanks to its integrated Alexa, this Nextbase Dash Cam allows for controlling your music, asking directions, and placing calls through voice commands. Its 3-inch touchscreen HD IPS screen provides an intuitive control interface as well.
Description
Quick Overview
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to control devices and run scenes in your Z-Wave network.
- Completely wireless
- Z-Wave Plus certified
- Supports 6 different actions/scenes
- Available in multiple colors (white black red blue yellow)
Product Details
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to manually activate and deactivate devices within your Z-Wave network and to activate scenes defined in your Z-Wave gateway.
The FIBARO Button supports up to 6 different actions/scenes which are triggered with one to five clicks or by holding the button down. In panic mode each press of the button results in triggering the emergency scene.
Designed to be small and light the FIBARO Button can be conveniently mounted on any surface and in any location (eg. beside the bed or under the desk)
Note: This device is currently only compatible with the FIBARO Home Center 3.
Product Support
Manuals:
⇒ FIBARO Button Product Support
Videos / YouTube:
⇒ Introducing the FIBARO Button
Technical Specifications
RF Protocol |
Z‐Wave Plus (500 series chip) |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Power |
ER14250 ½ AA 3.6V |
Operation Range |
Up to 40m indoors (with no obstacles) |
Application |
Indoor use only |
Operation temperature |
0 ~ 40 °C |
Storage temperature |
‐10 ~ 50 °C |
Weight |
80g |
Dimensions |
34mm x 46mm (height x diameter) |
Housing |
ABS |
@9/28
Description
Quick Overview
Colibri Z-Wave is the ideal solution for renovation projects and retrofitting. Simply select your range of wireless devices that we support and upgrade your existing home into a smart home.
Colibri enables system integrators and DIYs to integrate Z-Wave with other systems. Colibri supports: Z-Wave Modbus BACnet Google Assistant Amazon Alexa Sonos Samsung Smart TV LG Smart TV Philips Hue IP cameras DSC Paradox Satel Kodi Global Caché IRTrans TCP/IP devices Fronius and foobot.
Product Details
- Integrated Z-Wave Plus Interface
- Enables Z-Wave configuration
- bOS PRO License Included
- Plug & Play Installation
The first fully customizable Z-Wave visualization
Design your own custom GUI. Choose your favorite colors use your own icons use room photos as backgrounds or the layout of your smart home as a canvas for your buttons
Control From Your Favourite Mobile Platform or With Your Voice
You can use free bOS Client apps on any mobile device – iOS Android and Windows. And you can install them on as many mobile devices as you like no limitations. You can also you use Amazon Alexa or Google Assistant to control your smart building.
Advanced Logic And Tasks
One universal platform where all devices are working together offers a limitless number of different possibilities. Decide what happens with your smart building when you leave home when you go on holiday or in the morning bOS will make it happen. You can easily manage your schedules (e.g. raise shades at 7’o clock) scenes (e.g. romantic dinner Friday party etc.) and other automation tasks via bOS Client app on your favorite mobile device.
Design Your Own Awesome GUI
bOS will give you absolute flexibility with the design of your user interface. Choose your favorite colors use your own icons use room photos as backgrounds or the layout of your home as a canvas for your buttons. bOS Configurator is our free application for your system configuration. It makes the process of designing your GUI simple and fun. If you don’t have time to play around with the GUI you can choose your design from our extensive free library of templates icons and backgrounds.
Configuration Library
We have an extensive library of various bOS configuration examples. Select your heating pump AC TV or almost any other device and import it to your smart building configuration. We also encourage all system integrators add their own examples to ComfortClick library.
⇒ Examples Library
Product Support
Manuals:
Videos / Youtube:
⇒ Jigsaw the sharpest KNX server
⇒ ComfortClick YouTube Presentation
Technical Specifications
Software |
bOS PRO Licence for 2 users included |
Size: |
107mm x 61mm x 50mm |
CPU: |
1.2 GHZ quad-core ARM |
RAM: |
1 GB |
Disk size: |
SD card 32GB |
Connectors: |
4xUSB 1xEthernet port |
OS: |
Linux |
Power: |
100-240V 50/60 Hz |
Power consuption: |
~3-5 W |
Product code: |
CC-C-1 |
@96/119
Description
FIBARO Z-Wave Multi Sensor
| Quick Overview |
The Fibaro Motion Sensor is a universal Z-Wave multi-sensor. Along with detecting motion the device measures the temperature and light intensity. The sensor has a built-in accelerometer to detect anytampering of the device. The Fibaro Motion Sensor is battery powered device and designed to be installed quckly and easily on any surface. The LED indicator signals motion temperature level operating mode and can be used to see if device is within the Z-Wave network. The motion sensor can be used for lighting scenes and security monitoring systems
| Product Details |
– Compatible with any Z-Wave controller.
– Detects motion using a passive IR sensor.
– Measures the temperature.
– Measures the light intensity.
– Easy installation on a wall or any surface.
– Protected against tampering and theft – once vibrations are detected the notification is sent to the main controller.
– Alarms of movement and temperature are signaled by LED diode blinking.
– Simple earthquake detector mode.
The Fibaro Z-Wave Multi-Sensor can be recessed with the Universal Multisensor Recessor for discreet operation.
| Product Support |
Manuals:
⇒ FIBARO Z-Wave Multi Sensor Manual
Videos / YouTube: Motion Sensor
| Technical Specifications |
Product Name |
FIBARO MOTION SENSOR FGMS-001 V2.4 |
Battery Type |
CR123A battery 3.6 VDC |
Operation Range |
30m |
Light Intensity Measuring Range: |
0-32000 LUX |
Radio frequency |
921.42 MHz (AU/NZ Z-Wave) |
Power Consumption |
0 4W |
Operation temperature |
0 – 50C* |
| Measured temperature range | -20 to 100C |
Temperature measuring accuracy |
0 5 C |
Housing |
ABS |
Size (Diameter) |
44 mm |
@10/30
Description
Quick Overview
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to control devices and run scenes in your Z-Wave network.
- Completely wireless
- Z-Wave Plus certified
- Supports 6 different actions/scenes
- Available in multiple colors (white black red blue yellow)
Product Details
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to manually activate and deactivate devices within your Z-Wave network and to activate scenes defined in your Z-Wave gateway.
The FIBARO Button supports up to 6 different actions/scenes which are triggered with one to five clicks or by holding the button down. In panic mode each press of the button results in triggering the emergency scene.
Designed to be small and light the FIBARO Button can be conveniently mounted on any surface and in any location (eg. beside the bed or under the desk)
Note: This device is currently only compatible with the FIBARO Home Center 3.
Product Support
Manuals:
⇒ FIBARO Button Product Support
Videos / YouTube:
⇒ Introducing the FIBARO Button
Technical Specifications
RF Protocol |
Z‐Wave Plus (500 series chip) |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Power |
ER14250 ½ AA 3.6V |
Operation Range |
Up to 40m indoors (with no obstacles) |
Application |
Indoor use only |
Operation temperature |
0 ~ 40 °C |
Storage temperature |
‐10 ~ 50 °C |
Weight |
80g |
Dimensions |
34mm x 46mm (height x diameter) |
Housing |
ABS |
@9/28
Description
Aeotec Multisensor 7 Recessor
Quick Overview
Smart sensors.
Invisible sensors. Smart sensors. A smart home should be intelligent and it should be invisible. Recessor is the realisation of that principle. It connects to the AEOTEC MultiSensor 7 and AEOTEC TriSensor allowing either to be seamlessly installed and recessed within a wall or ceiling space. Recessor makes Z-Wave multi-sensors subtle.
Product Details
Still perfectly powered.
Whichever power method you’re using with your multi-sensor you can keep on using it with the AEOTEC Recessor.
The AEOTEC Recessor has been designed to allow for each sensor’s batteries to still easily be changed or for the AEOTEC MultiSensor 7’s optional power cable to be used if you prefer to power your sensor without batteries.
Still precise.
The AEOTEC Recessor doesn’t just convert the AEOTEC MultiSensor 7 into a Z-Wave ceiling or beam sensor it converts it into a precise sensor.
Once recessed your AEOTEC MultiSensor 7 can be angled up to 30º within the Recessor fine tuning its measurements and readings to be just where you need them.
Product Support
The perfect accessories. The AEOTEC MultiSensor 7 ships with 4 different accessories each designed to make the installation of the sensor perfect for your home.
Recessor.
Install the AEOTEC MultiSensor 7 in a ceiling or wall cavity with recessor (sold separately) and just 12 mm will extrude. Features magnetic clasps for simple removal of the sensor.
Mounting arm. (sold separately)
Discrete and for corner installations the mounting arm allows you to rotate MultiSensor 7 up to 360° and refine its field of view by up to 50°.
USB cable. (sold separately)
After 2 years you won’t have to change batteries if you power MultiSensor 7 via mains power using the provided 1.5 metre USB cable.
Tape.
Weighing only 74 grams the AEOTEC MultiSensor 7 can be easily installed with just the provided double sided tape from 3M.
Manuals:
⇒ Aeotec Multisensor 6 product manual
Technical Specifications
Application |
Indoor use only |
Operation temperature |
0 ~ 55 °C |
Storage temperature |
‐10 ~ 80 °C |
Color |
White |
Weight |
70g |
Housing |
ABS |
Dimensions |
(LxWxH) 86mm x 86mm x 43mm |
| Warranty | 12 Months |
@5/22
Description
VISION Z-Wave Outdoor Siren
Vision Z-Wave Outdoor Siren & Strobe – Wireless Smart Home Security Alarm
Enhance your smart home security with the Vision Z-Wave Outdoor Siren and Strobe. This fully wireless Z-Wave Plus device is compatible with all major Z-Wave gateway controllers making it a seamless addition to your Z-Wave system. It features a powerful 115 dB siren and bright blue flashing strobe to alert you instantly to any security breach. Designed for easy DIY installation this outdoor siren is IP66-rated for weather resistance—ideal for tough Australian conditions. Battery-operated (4 x D batteries included) with an estimated 2-year battery life this outdoor Z-Wave alarm offers reliable long-term protection for your home or business.
Quick Overview
The VISION Z-Wave Siren and Strobe DC is a wireless device capable of producing an audible and visual alarm.
- Blue LED flashing strobe light
- Loud (>115dB @ 1m) audible alarm
- Low battery and tamper indicators
- This device includes 4 DD batteries
- Configurable with Z-Wave-certified gateways
Product Details
Z-Wave Plus Outdoor Siren – Wireless Alarm with Visual & Audible Alerts
The Z-Wave Plus Outdoor Siren is a fully wireless programmable smart alarm designed to integrate seamlessly with any Z-Wave gateway. It delivers loud audible alerts and flashing visual warnings triggered by your Z-Wave network settings.
This outdoor siren is ideal for pairing with Z-Wave sensors to detect threats such as intrusion impact flooding or movement. Compatible devices include:
VISION Z-Wave Door/Window Multi-Sensor
VISION Z-Wave Shock Sensor
FIBARO Z-Wave Flood Sensor
FIBARO Z-Wave Multi-Sensor
You can also pair it with the FIBARO Z-Wave Button to create an easily accessible panic alarm for home or office use.
Additional features include a low battery indicator and a tamper alert which notifies your Z-Wave controller if the device is disturbed or removed—ensuring added security and peace of mind.
This product integrates with all Australian-certified (921.42MHz) Z-Wave controllers including:
- Fibaro Home Center 3/Lite
- Homeseer HS3
- REMOTEC Z-Wave Universal Remote Controller
- RaZberry Pi
- Resolution security panels
- Alarm.com security panels
Note: This device includes DD batteries.
Product Support
Manuals:
⇒ Outdoor Z-Wave Siren Manual (Size: 260 kB)
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer importer distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.
Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
Configuration Command Class:
Parameter 1: Siren/ Strobe Mode 1 Byte
Value: 0=Siren and Strobe enabled (default) 1=Siren only 2= Strobe only.
Parameter 2: Alarm auto stop time command 1Byte
Value: 0=30 seconds (default) 1= 60 secs 2= 120 secs 3= Siren will not stop automatically.
Federal Communications Commission Statement
This equipment has been followed to comply with Part 15 of the FCC Rules.
This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instruction may cause harmful interference to radio communications. However there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on the user is encouraged to try and correct the interference by one of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into and outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received including interference that may cause undesirable operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
Technical Specifications
RF Protocol |
Z‐Wave Z-Wave PLUS Certification |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐Wave |
Z‐Wave device type |
Z-Wave binary switch |
Internal Alarms |
Tamper Low Battery |
Operating Voltage |
4 DD batteries (included) |
Connection Type |
Wireless |
Operation Range |
Up to 50m indoor with no obstacles |
Application |
Outdoore IP 66 |
Operation temperature |
-10°C ~ 60°C |
Loud Audiable Alarm |
115dB @ 1meter |
Weight |
1.7 Kg |
Housing |
ABS |
Dimensions |
(H x W x D) 220mm x 200mm x 65mm |
Compliance |
RCM CE |
@20/44
Description
| Quick Overview |
The FAKRO Z-Wave™ ZWK10 Wall Controller is a wall-mounted multi-purpose remote that’s capable of operating up to 10 different FAKRO and Z-Wave™ devices. For the simplest solution to managing your range of Z-Wave™ and FAKRO devices the FAKRO Z-Wave ZWK10 Wall Controller has everything you need.
- Easy to install and include in your existing Z-Wave™ network setup
- Integrates easily and operates FAKRO window openers as well as other Z-Wave™ devices
- Manage and operate multiple devices using just one controller
- Can work as a Primary or Secondary controller
- Setting Mode (Inclusion/Exclusion/Association/Learning/Shift)
| Product Details |
The FAKRO Z-Wave ZWK10 Wall Controller is a smart device that enables you to manage several aspects of your home. Through radio communication processing the FAKRO Z-Wave ZWK10 Wall Controller can interact with 10 devices at once split into 5 different communication channels (2 devices for 1 channel). You can also categorize devices into 10 independent groups based on their location and functionality around the home.
The FAKRO Z-Wave ZWK10 Wall Controller can also be customized to operate as a PRIMARY controller for a single radio network or as a SECONDARY controller for a pre-existing network.
Configuring the controller to operate with each device is a simple process. Each device around the home is given a unique number (known as ‘NodeID’) and calibrated to operate on a single Z-Wave™ radio network (called ‘HomeID’).
Featuring a magnetic wall holder the FAKRO Z-Wave ZWK10 Wall Controller can be mounted onto any location around the home for quick and easy access. This convenient all-in-one solution can operate multiple FAKRO and Z-Wave-related products.
This product is compatible with:
- Fibaro Lite
- Fibaro Home Center 3
- FAKRO Z-Wave window automation products
| Product Support |
Manuals:
⇒ FAKRO Z-Wave ZWK10 Wall Controller Manual (Size: 2.75MB)
Videos / YouTube:
⇒ FAKRO Z-Wave ZWK10 Wall Controller – Setting up with FAKRO window automation
⇒ FAKRO Z-Wave ZWMP Weather Module – Setting up FAKRO window automation Part 1
⇒ FAKRO Z-Wave ZWMP Weather Module – Setting up FAKRO window automation Part 2
| Technical Specifications |
RF Protocol |
Z‐Wave™ |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Z‐Wave device type |
Z-Wave Controller |
Status Indicator |
LED Lights |
Operation Range |
Up to 40m without obstacles |
Power |
3V DC Battery 2xAAA 1 5 V |
Operation temperature |
+5 ~ 45 °C |
Dimensions L x W x H |
80mm x 80mm x 30mm |
Weight |
180g |
Housing |
ABS |
@19/43
Description
Quick Overview
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to control devices and run scenes in your Z-Wave network.
- Completely wireless
- Z-Wave Plus certified
- Supports 6 different actions/scenes
- Available in multiple colors (white black red blue yellow)
Product Details
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to manually activate and deactivate devices within your Z-Wave network and to activate scenes defined in your Z-Wave gateway.
The FIBARO Button supports up to 6 different actions/scenes which are triggered with one to five clicks or by holding the button down. In panic mode each press of the button results in triggering the emergency scene.
Designed to be small and light the FIBARO Button can be conveninetly mounted on any surface and in any location (eg. beside the bed or under the desk)
Note: This device is currently only compatible with the FIBARO Home Center 3.
Product Support
Manuals:
⇒ FIBARO Button Product Support
Videos / YouTube:
⇒ Introducing the FIBARO Button
Technical Specifications
RF Protocol |
Z‐Wave Plus (500 series chip) |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Power |
ER14250 ½ AA 3.6V |
Operation Range |
Up to 40m indoors (with no obstacles) |
Application |
Indoor use only |
Operation temperature |
0 ~ 40 °C |
Storage temperature |
‐10 ~ 50 °C |
Weight |
80g |
Dimensions |
34mm x 46mm (height x diameter) |
Housing |
ABS |
@9/28
Description
Quick Overview
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to control devices and run scenes in your Z-Wave network.
- Completely wireless
- Z-Wave Plus certified
- Supports 6 different actions/scenes
- Available in multiple colours (white black red blue yellow)
Product Details
The FIBARO Button is a compact battery-powered Z-Wave Plus device that allows you to manually activate and deactivate devices within your Z-Wave network and to activate scenes defined in your Z-Wave gateway.
The FIBARO Button supports up to 6 different actions/scenes which are triggered with one to five clicks or by holding the button down. In panic mode each press of the button results in triggering the emergency scene.
Designed to be small and light the FIBARO Button can be conveniently mounted on any surface and in any location (eg. beside the bed or under the desk)
Note: This device is currently only compatible with the FIBARO Home Center 3.
Product Support
Manuals:
⇒ FIBARO Button Product Support
Videos / YouTube:
⇒ Introducing the FIBARO Button
Technical Specifications
RF Protocol |
Z‐Wave Plus (500 series chip) |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
Power |
ER14250 ½ AA 3.6V |
Operation Range |
Up to 40m indoors (with no obstacles) |
Application |
Indoor use only |
Operation temperature |
0 ~ 40 °C |
Storage temperature |
‐10 ~ 50 °C |
Weight |
80g |
Dimensions |
34mm x 46mm (height x diameter) |
Housing |
ABS |
@9/28
Description
Quick Overview
The QUBINO Dimmer (by GOAP) is the first MOSFET-switching light Z-Wave dimmer module that also supports control of low-voltage halogen lamps with an electronic transformer dimmable compact fluorescent lights and dimmable LED bulbs. It also measures the power consumption of electrical devices and supports the connection of a digital temperature sensor.
QUBINO modules are “install-and-forget” products. Our products are made to last so we only select and use top-quality electronic components. These modules are also the most tested Z-Wave microcontrollers on the market. The Slovenian Institute of Quality and Metrology (SIQ) an independent testing body tests safety parameters including temperature rise construction insulation resistance power consumption and overload following the EN 60669-2-1 standard.
Product Details
All QUBINO modules are manufactured in Europe by GOAP.
- The QUBINO Z-Wave Dimmer module occupies a smaller volume than comparable modules of any other brand and will fit easily in any flush mounting box.
- The QUBINO Z-Wave Dimmer can measure the power consumption of the connected electrical device and itself has an extremely low power consumption of just 0.7 W.
- The QUBINO Z-Wave Dimmer can operate across a wide temperature range from a chilly -10˚C to a scorching 40˚C (14˚–104˚F). It supports the connection of a digital temperature sensor which is also useful for creating complex scenarios. Every module also acts as a repeater in order to improve the range and stability of the Z-Wave network.
- Unlimited controlling capability through gateway
- Setting mono-stable (push button) or bi-stable switch type
- Z-Wave Plus compliant
- 23 additional parameters for expert users
Product Support
Please note: If you are installing the entire Z-Wave™ system for the first time please refer to the installation guide of your Z-Wave gateway before installing this device.
The QUBINO Flush Dimmer uses a unique MOSFET ‘trailing edge’ dimmer to enable it to work with a huge range of bulb types:
Halogen and Incandescent (230V) – up to 140W
Dimmable LEDs (230V) – up to 30W
Dimmable CFL and Fluorescent (230V) – up to 30W
Low Voltage Halogen (24V)
Low Voltage LED (24V)
The QUBINO Dimmer can be used in the 230V mains lighting system where it uses a ‘Trailing Edge’ style dimmer to control the lights. It can also be used in a 24V low-voltage system where it uses PWM style control of the bulbs.
Configuring Z-Wave Devices:
Z-Wave devices often have several configurable parameters which you can change using your Vera’s user interface. These parameters can include things such as the length of time a Z-Wave siren remains active for or the type of manual switch connected to a Z-Wave light controller.
Every available configurable parameter is listed in your device’s user manual. In most cases your device’s default parameters will be suitable to your needs however sometimes it may be necessary to adjust them to optimally use your device. A guide to configuring Z-Wave devices with Vera UI7 is available in the Manuals section.
Please note:
These devices require a 3-wire system (including neutral) please check your installation before purchasing. If you have 2-wire system (without neutral) we recommend you use a FIBARO Z-Wave Dimmer 2
PLEASE NOTE FOR THE INSTALLATIONS IN THE AREAS WHERE ELECTRICITY SUPPLIERS USING OFF-PEAK RIPPLE CONTROL SIGNALS:
Electricity suppliers in particular areas of Australia such as NSW QLD and some others places are injecting an off-peak ripple control signal using Zellweger equipment or similar onto their distribution networks in order to remotely control devices such as off-peak hot water systems and street lighting although other areas within Australia also use this technology. Not all properties are affected by ripple control so just because you might live in one of these areas does not mean that you will have these problems.
Ripple injection control systems work by superimposing coded control signal commonly 750Hz or 1050Hz on the 50 Hz mains supply.
Some electrical appliances such as fans dimmers toasters and LED lighting can be sensitive to this ripple control signal. The results could be audible buzzing noises from fans or flickering lights whenever the ripple control signals are present.
Electricity suppliers are advising users to install appropriate ripple signal filters in such areas.
The ripple signal filter is a tuned passive inline filter which completely eliminates the superimposed ripple injection control signal from the normal mains supply to produce a noise free filtered mains supply which can then be connected to the electrical appliances or light control systems. The ripple signal filter is specifically tuned to eliminate the ripple control signal frequency of 750Hz or 1050Hz.
However we can’t guarantee the ripple signal filter always will help you if you experiencing such issues. Please contact your local energy provider to get more information and proposed solutions for your electrical installation.
If you are getting similar problems with your dimmers and fans and it’s not Ripple Control Signal and you are hearing the tones at random times of the day your electrical supply may be affected by harmonics; a power fluctuation that is not part of the normal electricity supply or ripple control signal output.
Harmonics are caused by an interference created by other equipment on the network such as inverter type air conditioners and switch mode power supplies for computers.
The offending appliances may be in your home or other premises on the local power grid. If you are being affected by network harmonics it may be of benefit to transfer the electricity supply to your premises to a different phase in the street. This is something you will need to discuss with your electrical company.
We are strongly recommending for the areas we have mentioned above to run test with only few dimmers before committing for high volumes. If results are not fully OK you may use relays only instead of dimmers.
Please note that our warranty for the faulty devices is not covering above mentioned conditions with your local electric grids.
Please see affected with Ripple Signalling areas here:
QUEENSLAND
- Only Southern Queensland (Energex) has Ripple Signalling.
- The Frequency is 1050Hz.
- The rest of Queensland (Ergon) does not have Ripple Signalling.
NSW
- Energy Australia Full Supply Area
- Energy Australia Sydney &Hunter Supply Area
Manuals:
⇒ QUBINO Z-Wave Dimmer InWall Installation Manual
⇒ QUBINO Dimmer Two-Way Bell Press Switch Wiring Diagram (191KB)
⇒ QUBINO Dimmer Two-Way Toggle Switch Wiring Diagram (191KB)
⇒ Guide to Configuring Z-Wave Devices with Vera UI7 (Size: 435 kB)
Videos / YouTube:
⇒ QUBINO Dimmer dimming a 24V DC LED Strip Lights
Technical Specifications
RF Protocol |
Z-Wave Plus™ SDK version: 6.51.03 |
RF Frequency |
921.42Mhz ‐ AU/NZ approved RF for Z‐wave |
|
Application
Max output circuit power of AC/DC for resistive load only
Max output circuit power of AC/DC
for LED bulb and low voltage halogen bulbs with electronic transformer |
Indoor use only
140W (240VAC) – 21W (24VDC) – Resistive load
30W (240VAC) / 15W (110VAC) – LED load
|
Power |
0.6 A / 230 VAC
0.85 A / 30 VDC
|
Operation Range |
Up to 30m indoors with no obstacles |
Enclosure |
Plastic |
Comliance |
EN 60669-2-1 |
| Operating Temp. | -10C ~ +40C |
Dimensions |
41.8mm x 36.8mm x 15.4mm |
@9/28
Description
| Quick Overview |
Installed in conjunction with the FAKRO ZWMP Weather Module the FAKRO ZRD Rain Sensor can automatically close any window installation upon detecting rainfall.
- Installed in conjunction with the FAKRO ZWMP Weather Module
- Automatically closes windows upon detecting rainfall
- Fitted heating elements to prevent interference from fog mist and other weather conditions
- Suitable for installation in an unsheltered area
| Product Details |
When you’re away from home the FAKRO ZRD Rain Sensor is the perfect solution for dealing with unpredictable weather changes. When the ZRD Rain Sensor detects rainfall it will automatically close any motorized windows situated around the home. The ZRD Rain Sensor can work in conjunction with many window installation types including skylights awnings and much more. By having every aspect of the home regularly monitored the system can immediately react to changes in weather.
When you install the ZRD Rain Sensor in conjunction with the FAKRO ZWMP Weather Module all that’s required is linking up each window installation with the Weather Module in order for the devices to interact with one another.
| Product Support |
Manuals:
⇒ FAKRO ZRD Rain Sensor User Manual (Size: 651 KB)
Videos / Youtube:
⇒ FAKRO Z-Wave ZWMP Weather Module – Setting up FAKRO window automation Part 1
⇒ FAKRO Z-Wave ZWMP Weather Module – Setting up FAKRO window automation Part 2
| Technical Specifications |
Power supply |
8 -32 V DC (not incl. powered by ZWMP Weather Module) |
| Dimentions | 55mm x 50 mm x 15mm |
| Power cord | 3 x 0.25 mm2 (5 m included) |
@9/28
Description
Quick Overview
Fibaro Flood Sensor is a universal Z-Wave compatible flood and temperature sensor. The device can be battery (ca. 2 years battery life) or VDC powered (12 or 24 VDC). The flood alarm is sent to the Z-Wave network devices or to any alarm system controller through opening a NC contact.
The device has a built-in temperature sensor to monitor the temperature of the floor for example. Fibaro’s Flood Sensor is designed to be placed on the floor or on a wall with a flood sensor probe extended by a connected wire. The device has a built in LED indicator and acoustic alarm. Additionally the sensor is equipped with a tilt sensor reporting tilt or movement to the main controller (e.g. when someone has taken the Sensor from its original location).
The LED diode signals flood operating mode or the Z-Wave
network communication range. What’s more the device is also sink-proof which means it drifts on the water surface and keeps sending alarm signals in case of substantial inundation of water.
Compatible with – Fibaro Home Center 2/Lite controllers as well as Fibaro Home Center 3 Fibaro Home Center 3 Lite and Fibaro Nice Yubii Home Controller
@11/31
