Products

Warranty Period: 3-Year

@0/40

Warranty Period: 3-Year

@0/47

Warranty Period: 3-Year

@11/25

Built-in 9dBi 2x2 dual-polarized directional MIMO antenna Adjustable transmission power from 0 to 27dBm/500mw System-level optimizations for more than 5km long range wireless transmission TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput capacity and latency performance ideal for PTMP applications Centralized Management System – Pharos Control AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

HARDWARE FEATURES Processor Qualcomm Atheros 560MHz CPU MIPS 74Kc Memory 64MB DDR2 RAM 8MB Flash Interface 1 10/100Mbps Shielded Ethernet Port (LAN0 Passive PoE in) 1 10/100Mbps Shielded Ethernet Port (LAN1 Passive PoE Passthrough) 1 Grounding Terminal 1 Reset Button Power Supply Passive Power over Ethernet via LAN0 (+4 5pins; -7 8pins) Voltage range: 16-27VDC Power Consumption 10.5 Watts Max Note: When deployed using Passive PoE the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. Dimensions ( W x D x H ) 224 x 79 x 60 mm Antenna Type Built-in 9dBi 2x2 Dual-polarized Directional Antenna Beam Width: 65° (H-Plane) / 35° (E-Plane) Note: For more details please refer to datasheet Protection 15KV ESD Protection 6KV Lightning Protection Enclosure Outdoor ASA stabilized plastic material IPX5 waterproof Certification WIRELESS FEATURES Wireless Standards IEEE 802.11b/g/n (with Pharos MAXtream disabled) Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled) Wireless Speeds Up to 300Mbps (40MHz Dynamic) Up to 144.4Mbps (20MHz Dynamic) Up to 72.2Mbps (10MHz Dynamic) Up to 36.1Mbps (5MHz Dynamic) Frequency 2.4~2.483GHz Note: Available operating frequency may vary depending on the limitation

@20/19

Built-in 12dBi 2x2 dual-polarized directional MIMO antenna Adjustable transmission power from 0 to 30dBm/1000mw System-level optimizations for more than 13km long range wireless transmission TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput capacity and latency performance ideal for PTMP applications Centralized Management System – Pharos Control AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

HARDWARE FEATURES Processor Qualcomm Atheros 560MHz CPU MIPS 74Kc Memory 64MB DDR2 RAM 8MB Flash Interface 1 10/100Mbps Shielded Ethernet Port (LAN0 Passive PoE in) 1 10/100Mbps Shielded Ethernet Port (LAN1 Passive PoE Passthrough) 1 Grounding Terminal 1 Reset Button Power Supply Passive Power over Ethernet via LAN0 (+4 5pins; -7 8pins) Voltage range: 16-27VDC Power Consumption 10.8 Watts Max Note: When deployed using Passive PoE the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. Dimensions ( W x D x H ) 11×3.1×2.1 inch (276×79×60 mm) Antenna Type Built-in 12dBi 2x2 Dual-polarized Directional Antenna Beam Width: 60° (H-Plane) / 30° (E-Plane) Note: For more details please refer to datasheet Protection 15KV ESD Protection 6KV Lightning Protection Enclosure Outdoor ASA stabilized plastic material IPX5 waterproof Certification WIRELESS FEATURES Wireless Standards IEEE 802.11b/g/n (with Pharos MAXtream disabled) Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled) Wireless Speeds Up to 300Mbps (40MHz Dynamic) Up to 144.4Mbps (20MHz Dynamic) Up to 72.2Mbps (10MHz Dynamic) Up to 36.1Mbps

@26/23

Up to 300Mbps on 5GHz wireless data rates 23dBi high-gain directional 2×2 MIMO antenna and a dedicated metal reflector ideal for long-distance application Excellent beam directivity improved latency and noise cancellation Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE610 stable even in strong winds Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability TP-Link Pharos MAXtream TDMA technology improves throughput capacity and latency performance Pharos Control gives administrators a free centralized management system AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes Passive PoE supports to allow flexible deployment and convenient installation

HARDWARE FEATURES Processor Qualcomm 560MHz CPU MIPS 74Kc Memory 64MB DDR2 RAM 8MB Flash Interface 1 1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button Power Supply Passive Power over Ethernet via LAN (+4 5pins; -7 8pins) Voltage range: 16-27VDC Dimensions 360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount) Antenna Gain 23dBi Antenna Beamwidth 9°(Azimuth) 7°(Elevation) Protection 15KV ESD Protection 6KV Lightning Protection Enclosure Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design

WIRELESS FEATURES Wireless Standards IEEE 802.11a/n Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled) Wireless Speeds Up to 300Mbps (40MHz Dynamic) Up to 144.4Mbps (20MHz Dynamic) Up to 72.2Mbps (10MHz Dynamic) Up to 36.1Mbps (5MHz Dynamic) Frequency 5.15~5.85GHz Transmit Power Max. 29dBm/790mW (Adjustable power by 1dBm)

SOFTWARE FEATURES Operating Modes AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP Client)

@35/29

HARDWARE FEATURES Processor Qualcomm 750MHz CPU MIPS 74Kc Memory 128 MB DDR2 RAM 16 MB Flash Interface 1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button Power Supply Passive Power over Ethernet via LAN (+4 5pins; -7 8pins) Voltage range: 16-27V DC Dimensions ( W x D x H ) 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) Antenna Gain 23 dBi Antenna Beamwidth 9° (Azimuth)/7° (Elevation) Protection 15 KV ESD Protection 6 KV Lightning Protection Enclosure Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design

WIRELESS FEATURES Wireless Standards IEEE 802.11a/n/ac Wireless Speeds Up to 867 Mbps (80 MHz Dynamic) Up to 400 Mbps (40 MHz Dynamic) Up to 173.4 Mbps (20 MHz Dynamic) Frequency 5.15~5.85 GHz Transmit Power Max. 27 dBm (Adjustable power by 1dBm)

SOFTWARE FEATURES Network Configuration WAN: Static/ Dynamic/ PPPoE LAN: Static/ Dynamic/ DHCP Forwarding: ALG/ UPnP/ Virtual Server/ Port Trigger Security: SPI Firewall/ Ping Forbidden/ DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding

POE ADAPTER FEATURES Dimensions(W x D x H) 85.8×43.9×29.7 mm

@42/33

Warranty Period: 3-Year

@0/38

@0/50

Warranty Period: 3-Year

@0/56

11 Gbps Tri-Band Wi-Fi – 5760 Mbps (6 GHz) + 4320 Mbps (5 GHz) + 574 Mbps (2.4 GHz).† 2.5 Gbps Wired Connections – 4× 2.5 Gbps ports ensure max flexibility and boosted throughput.§ Wireless and Wired Combined Backhaul – Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency. Multi-Link Operation (MLO) – Simultaneously send and receive data across different bands and channels to increase throughput reduce latency and improve reliability.△ 320 MHz Channels – Double the bandwidth and enables many more simultaneous transmissions at the fastest possible speeds.△ Works on the 6 GHz Band – Minimizes congestion with greenfield spectrum delivering robust high-speed connections.△ TP-Link HomeShield – Provides comprehensive network protection robust parental controls and real-time IoT security.* Universal Compatibility – Backward compatible with all Wi-Fi generations and works with any internet service provider (ISP) and modem.☆

@0/72

@0/79

@0/87

Warranty Period: 3-Year

@0/91

@0/53

@0/97

@0/71

@0/100
