Networking

Warranty Period: 3-Year

@64

@0/43

@64

@0/50

@86

@105

@0/53

@102

@0/58

@49/41

@37/30

Warranty Period: 5-Year

@33/26

@49/41

Warranty Period: 5-Year

@105

Warranty Period: 5-Year

@0/53

Complies with 802.3u 10/100Base-TX 100Base-FX standards. Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely Adopts WDM technology transmitting and receiving data on one single fiber

What This Product Does The MC112CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Adopting WDM technology MC112CS takes only one fiber cable to transmit and receive data which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards the MC112CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINK’s media converter MC111CS is just one of the examples to cooperate with MC112CS.

MEDIA CONVERTER & MODULE Standards and Protocols IEEE 802.3 IEEE 802.3u IEEE 802.3x Basic Function Adopts WDM technology Half/Full-Duplex transfer mode for FX port Full Duplex Flow Control (IEEE 802.3x) Half Duplex Flow Control (Backpressure) Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely Extends fiber distance up to 20km Ports 1 100M SC/UPC port 1 100M RJ45 port (Auto MDI/MDIX) Wave Length 1310nm Tx/1550nm Rx WDM TX 1310nm WDM RX 1550nm Network Media 10BASE-T UTP category 3 4 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) Network Media 100BASE-T UTP category 5 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) Network Media 100BASE-FX Single-mode Fiber LED Indicators PWR FDX/Col Link/Act SPD Power Supply External Power Adapte

@12/21

* BE3600 Dual-Band Wi-Fi 7 (2882 Mbps on 5 GHz + 688 Mbps on 2.4 GHz).† * 1× 2.5G port unlocks the full potential of Wi-Fi 7. * 160 MHz bandwidth enables many more simultaneous transmissions.‡ * Multi-RUs ensure the high performance of your network.‡ * Advanced Functions: Centralised management Mesh and Seamless Roaming.

Warranty Period: 5-Year

@56/48

* Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)** Centralized Cloud Management and Intelligent Monitoring. * Centralised Management: Cloud access and Omada app for ultra convenience and easy management. * Gigabit Ports: 1 gigabit SFP and 5 gigabit RJ45 ports provide high-speed wired connectivity. * Up to 4 WAN Ports: 1 gigabit SFP WAN port 1 gigabit RJ45 WAN port 2 gigabit WAN/LAN ports optimize bandwidth usage. * Highly Secure VPN: Supports up to 100× LAN-to-LAN IPsec 50× OpenVPN* 50× L2TP and 50× PPTP VPN connections. * Abundant Security Features: Advanced firewall policies DoS defense IP/MAC/URL filtering and more security functions protect your network and data.

HARDWARE FEATURES Standards and Protocols * IEEE 802.3 802.3u 802.3ab * TCP/IP DHCP ICMP NAT PPPoE SNTP HTTP DNS IPsec PPTP L2TP Interface * 1 Fixed Gigabit SFP WAN Port * 1 Fixed Gigabit RJ45 WAN Port * 2 Fixed Gigabit RJ45 LAN Ports * 2 Changeable Gigabit RJ45 WAN/LAN Ports Network Media * 10BASE-T: UTP category 3 4 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) * 100BASE-TX: UTP category 5 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) * 1000BASE-T: UTP category 5 5e 6 cable (Max 100m) Button Reset Button Power Supply 100–240 V~50/60 Hz Flash SPI 4MB + NAND 128MB DRAM 512MB LED PWR SYS SFP WAN Speed Link/Act Dimensions ( W x D x H ) 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)

@58/50
