Powerful Features
|
|
•
|
1/2.5" 8 Megapixel Progressive Scan CMOS
|
•
|
Max. 20 fps @ 8 MP (3840 x 2160)
|
•
|
2.7~12mm Motorized (view: 115° ~ 35°) lens
|
•
|
H.265+ / H.265 / H.264+ / H.264 / MJPEG Triple Streams
|
•
|
WDR (120dB Wide Dynamic Range)
|
•
|
Day/Night(ICR) AWB AGC BLC
|
•
|
3D Digital Noise Reduction
|
•
|
EXIR Smart IR LEDs range: up to 50m night vision
|
•
|
Support on-board storage up to 120 GB
|
•
|
Line Crossing Intrusion Face Detection Unattended Baggage Object Removal
|
•
|
IP67 DC12V PoE (802.3at)
|
•
|
Ø144.13 x 332.73 mm 1.893 Kg
|
Technical Specifications
DS-2CD2685FWD-IZS | |
Image Sensor | 1/2.5" 8 Megapixel Progressive Scan CMOS |
Effective Pixels | 8 MP (3840 x 2160) |
Electronic Shutter | 1/3 s to 1/100 000 s |
Synchronization | Internal |
Min. Illumination | 0.01Lux 0Lux IR on |
Camera Features | |
Max. IR LEDs Length | 50m Smart IR |
Day/Night | Auto(ICR) / Color / B/W |
Noise Reduction | 3D |
Lens | |
Focal Length | 2.7~12mm Motorized (view: 115° ~ 35°) Lens |
Mount Type | Board-in Type |
Video | |
Compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG Triple Streams |
Resolution | Up to 8 MP (3840 x 2160) |
Frame Rate | 20fps@8 MP (3840 x 2160) |
Network | |
Ethernet | 1 x RJ-45 (10/100Base-T) |
Protocol | TCP/IP UDP ICMP HTTP HTTPS FTP DHCP DNS DDNS RTP RTSP RTCP PPPoE NTP UPnP SMTP SNMP IGMP 802.1X QoS IPv6 |
ONVIF | ONVIF (Profile S Profile G) PSIA CGI ISAPI |
Client | iVMS-4200 Hik-Connect iVMS-5200 iVMS-4500 |
Smart Feature-set | |
Line Crossing Detection | Cross a pre-defined virtual line |
Intrusion Detection | Enter and loiter in a pre-defined virtual region |
Unattended Baggage | Objects left over in the pre-defined region such as the baggage purse dangerous materials |
Object Removal | Objects removed from the pre-defined region such as the exhibits on display |
Recognition | Face Detection |
Auxiliary Interface | |
On-board storage | Built-in Micro SD/SDHC/SDXC slot up to 120GB |
General | |
Power Supply | DC12V PoE (802.3at) |
Power Consumption | Max 19W |
Working Environment | -30°C~+60°C / Less than 95%RH (no condensation) |
Ingress Protection | IP67 |
Dimensions | Ø144.13 x 332.73 mm |
Weight | 1.893 Kg |
