COMFORT AND CONVENIENCE IN A WIRELESS HEADSET
WIRELESS FOR GREATER FREEDOM
The Logitech H820e Headset stays connected within 100 meters of your desk, with up to 10 hours of wideband talk time. The headset’s DECT wireless connectivity won’t interfere with Wi-Fi devices in your office.
IDEAL FOR BUSY OFFICES
Phone calls in active work environments can be difficult. The H820e Headset is designed for these situations. The headset automatically pairs with any H820e dock – ideal for hot desking. An LED lets others know you’re on the phone, while a visual indicator tells you when you have an incoming call.
DESIGNED FOR BUSINESS
The H820e Headset is certified for use with leading conference software applications such as Skype for Business and Cisco® Jabber™. H820e is recommended for heavy-duty business users in open workspaces, offices, or home offices. Choose H820e Mono or H820e Dual for one or two speakers.
AUTOMATIC PAIRING
H820e headsets automatically pair when placed in any H820e charger dock, making it easy to use the headsets with any workstation in large deployment or hot desking situations.
CONVENIENT CONTROLS
Control the call with on-ear answer/end1 and volume up/ down buttons. The raised button design provides a point of reference for your fingers so you can feel the buttons you’re pressing. Mute and unmute with a tactile button on the adjustable boom.
NOISE & ECHO CANCELLATION
With acoustic echo cancellation and a noise-cancelling microphone, H820e is optimized so you can hear and be heard, even in noisy workspaces.
YES, I’M ON A CALL
Located on the backside of the boom, an LED indicator provides a visual alert to those behind you that you are on a call, preventing accidental disturbances during calls.
Specifications
|
DIMENSIONS
|
|
|
HEADSET
|
|
|
Height x width x depth
|
165 mm x 174 mm x 50 mm
|
|
Weight
|
128 g (Dual)
|
|
Weight
|
88 g (mono)
|
|
BASE
|
|
|
Height x width x depth
|
128 mm x 73 mm x 82 mm
|
|
Weight
|
475 g
|
|
SYSTEM REQUIREMENTS
|
|
|
COMPATIBLE WITH
|
Windows Vista , Windows 7 or Windows 8 (32 - bit or 64 - bit), Windows 10
|
|
Mac OS X 10.7 or later
|
|
|
Linux
|
|
|
Free USB port
|
|
|
Network operation
|
|
|
DRIVER / SOFTWARE DOWNLOADS
|
|
|
Recommended
|
Plug-ins for Jabber and Skype
|
|
Availability
|
|
|
APPLICATION COMPATIBILITY
|
Compatible with the most popular UC platforms such as Skype and Skype for Business, Google Hangouts Pro, Cisco 1 and more.
|
|
CERTIFICATIONS
|
Certified for Skype for Business, 1 compatible with Cisco .
|
|
OTHER PRODUCT FEATURES
|
Red LED light for "On Call" indicator on back of the bracket
|
|
Red Mute LED on the bracket
|
|
|
TECHNICAL SPECIFICATIONS
|
|
|
MICROPHONE (TX)
|
|
|
Type
|
ECM bidirectional
|
|
Frequency range
|
100 Hz to 7 kHz
|
|
Sensitivity
|
-45 dB +/- 3 dB
|
|
Distortion
|
<10% at 1 kHz, 10 dBPa (MRP) input
|
|
Operating voltage
|
1.4-5.0 V DC
|
|
SPEAKERS (RX)
|
|
|
Frequency range
|
150 Hz to 7 kHz (ITU-T TIA920)
|
|
Sensitivity
|
103 dB 3 dB at 1 kHz, input 1 mW / Type 4153 Artificial Ear
|
|
Distortion
|
<4% at 1 kHz, 0 dBm0, 1 kHz
|
|
BATTERY PACK
|
|
|
Type
|
Lithium-Ion
|
|
Weight
|
9 g
|
|
Capacity
|
430 mAh
|
|
CONTENT
|
Headset charging station
|
|
Power supply
|
|
|
USB cable
|
|
|
Quick start guide and warranty card
|
|
|
GUARANTEE
|
2 years limited hardware warranty
|
|
ITEM NUMBER
|
|
|
MONO
|
Part no. 981-000512 |
